Innofill Glass MF bottle filler

High-quality filling designed for high-proof products

Innofill Glass MF bottle filler

Good to know

It goes without saying that your valuable alcoholic beverages need special attention. The Innofill Glass MF meets this requirement in every respect. The advanced vacuum filling method of this modern filling system assures exact filling of spirits in glass bottles. Variable with regard to the type of beverage and bottle, this precision system is capable of achieving filling capacities of up to 40,000 bottles an hour. The Innofill MF is available with various capacity levels as a single machine or monoblocked with a bottle rinser.

Well thought out

The push-button fill level adjustment of the Innofill Glass MF ensures short changeover for both product and bottle type changing. The principle of controlled vacuum use minimizes alcohol and flavor losses to the greatest possible extent. It additionally enables you to fill high viscosity products drip-free. The Innofill Glass MF is thus the ideal bottling system for all types of spirits.

Convincing

  • Vacuum filling method ensures exact fill levels.
  • Using only a few moveable parts simplifies and makes operating more reliable and at the same time cuts the cost of maintenance
  • Automatic fill level adjustment means short changeover and increased flexibility

Sustainable

  • Minimize your product losses through drip-free filling

Good to know: with our platform system you can add modules to your machinery to allow you to flexibly process further beverage types or container sizes in the future. This means that you are all set up to meet constantly changing future market challenges today. Invest in the long term and benefit from efficient maintenance and an optimum supply of spare parts – for increased line availability.

Consumables

KHS MULTI GREASE 01

KHS MULTI GREASE 01 is an high performance extreme pressure lubricant. It is suitable for centralised lubrication systems.

Material numbers: 301142150102, 301142150106, 301142150108

KHS SEAL & SILICONE GREASE 04

KHS Seal & Silicone Grease 04 is a high performance silicone lubricant specially developed for the grease lubrication and sealing of tapes, valves and fittings with EPDM seals (ethylene-propylene-diene rubber) in the food and beverage processing and packaging industry, with good resistance to hot water, steam and disinfectant solutions.

Material numbers: 301142150403

KHS LIFT FLUID AS 32

KHS Lift Fluid AS 32 is a fully synthetic high performance hydraulic fluid for long maintenance intervals. KHS Lift Fluid AS 32 contains an antimicrobial preservative to protect the lubricant from deterioration, fouling and odour caused by microorganisms.

Material numbers: 301142110805, 301142110811

KHS GEAR FLUID 150

KHS Gear Fluid 150 is a fully synthetic high performance gear oil with EP properties.

Material numbers: 301142110912

KHS GEAR FLUID 460

KHS Gear Fluid 460 is a fully synthetic high performance gear oil with EP properties which have been specially developed for use in machinery used in the food and beverage processing and packaging industry.

Material numbers: 301142110207, 301142110209
