Innofill PET NV PET filler

Still water bottling at maximum capacity

Innofill PET NV PET filler

Good to know

With the Innofill PET NV we offer you modern, computer-controlled precision technology for your sophisticated products. This exact-amount, high-performance system is capable of achieving outstanding filling capacities of up to 81,000 bottles an hour. On request we provide the Innofill PET NV either as a single machine, blocked with a bottle rinser and stretch blow molder as the InnoPET BloFill or as the InnoPET TriBlock Aqua with a stretch blow molder and labeler.

Well thought out

With its very short conversion times for product and/or bottle changeovers the Innofill PET NV gives you exceptionally high system availability. This PET bottle filler offers you high flexibility coupled with maximum performance according to your requirements. The new machine pitch of 25.7 pi yields a high performance density in the filler and capper for bottles with a maximum diameter of 75 mm. Larger bottle formats can be processed using the familiar machine pitches of 30 to 45 pi.

Boost the efficiency of your PET filling and packaging line with our KHS InnoPET iflex modular automation concept with fast and reliable changeovers.

All options open

Further reading

All options open

Standardized and technologically improved: the new PET filler platform makes filling with the Innofill PET NV more flexible and future-proof.

Learn more

Convincing

  • The free-flow filling principle ensures maximum microbiological and hygienic safety
  • Exact adherence to fill levels thanks to the volumetric filling system, either with electromagnetic inductive or mechanical flow metering for water with a low conductivity
  • Three available filling speeds for optimum filling quality

Sustainable

  • Reduce your product loss with low-foam filling combined with optimized bottle conveying through the filler carousel and screw capper
  • Hygienic design for easy, resource-saving sanitizing

Good to know: with our platform system you can add modules to your machinery to allow you to flexibly process further beverage types or container sizes in the future. This means that you are all set up to meet constantly changing future market challenges today. Invest in the long term and benefit from efficient maintenance and an optimum supply of spare parts – for increased line availability.

Images & videos

Consumables

KHS MULTI GREASE 01

KHS MULTI GREASE 01 is an high performance extreme pressure lubricant. It is suitable for centralised lubrication systems.

Material numbers: 301142150102, 301142150106, 301142150108

KHS SEAL & SILICONE GREASE 04

KHS Seal & Silicone Grease 04 is a high performance silicone lubricant specially developed for the grease lubrication and sealing of tapes, valves and fittings with EPDM seals (ethylene-propylene-diene rubber) in the food and beverage processing and packaging industry, with good resistance to hot water, steam and disinfectant solutions.

Material numbers: 301142150403

KHS GEAR FLUID 150

KHS Gear Fluid 150 is a fully synthetic high performance gear oil with EP properties.

Material numbers: 301142110912

KHS GEAR FLUID 220

KHS Gear Fluid 220 is a fully synthetic high performance gear oil with EP properties.

Material numbers: 301142110507

KHS GEAR FLUID 460

KHS Gear Fluid 460 is a fully synthetic high performance gear oil with EP properties which have been specially developed for use in machinery used in the food and beverage processing and packaging industry.

Material numbers: 301142110207, 301142110209
